HOUSING
• Injection-molded, engineering grade, 5VA flame retardant, high-impact resistant, thermoplastic in white or black finishes.
• EZ snap-out chevron directional indicators.
OPTIONS
• SDT: Self-diagnostic feature performs monthly, biannual, and annual tests to ensure reliable operation and meet electrical and life safety codes.
WARRANTY/LISTING
• Five year warranty on all electronics and housing. Battery pro rated for five years.
• Meets UL924, NFPA 101 Life Safety Code, NEC, OSHA, Local and State Codes.
• UL Listed for damp locations (0°C – 50°C).
ILLUMINATION
• Ultra bright, energy efficient white LED emergency lighting.
• 4.5W (36 LEDs x 0.125 watts) per light pipe.
• Adjustable high performance, smooth, chrome-plated, metallized reflector and acrylic, UV-stabilized “Light Pipe” lens for optimal light distribution.
• Long life, energy efficient Red or Green LED EXIT sign illumination.
ELECTRICAL
• Dual 120/277 voltage.
• Charge rate/power “ON” LED indicator light and push-to-test switch for mandated code compliance testing.
• 4.8V long life, maintenance-free, rechargeable NiCd battery.
• Internal solid-state transfer switch automatically connects the internal battery to LED board and LED Light Pipe for minimum 90-minute emergency illumination.
• Fully automatic solid-state, two rate charger initiates battery charging to recharge a discharged battery in 24 hours.
• Remote capable standard.
MOUNTING
• EZ-snap mounting canopy included for top or end mount.
• Universal K/O pattern on back plate for wall mount.
